Specifications

MAX RGT-75 Specifications

MAX RGT-75FI Specifications
*Other motor configurations available
Capacity- nominal 75 gpm (283 lpm)
Gas Dissolution- air by volume 60 cfh
Type Flex Coupled
Inlet/Outlet 2″ x 2″
Motor- 480v 3p standard* 15 hp, premium
Operating RPM @ 60hz* 1750
Material- Casing Ductile Iron
Material- Impeller Carbon Steel
MAX RGT-75FS Specifications
*Other motor configurations available
Capacity- nominal 75 gpm (283 lpm)
Gas Dissolution- air by volume 60 cfh
Type Flex Coupled
Inlet/Outlet 2″ x 2″
Motor- 480v 3p standard* 15 hp, premium
Operating RPM @ 60hz* 1750
Material- Casing 304 Stainless Steel
Material- Impeller 316 Stainless Steel
